Pumper Fire Truck

description1

Zipper closure 1/4 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout

Specifications

（1）All-Weather, Fully Automatic Water Supply System (200–300L/S)

Applicable Scope:Suitable for most water source areas, with high mobility and flexibility.

Performance:

	Pumper Fire Truck on 4x2 Chassis (Equipped with 1 Set of Floating Pump)
Specifications	Ø Each pumper fire truck and hose laying fire truck requires only 1–2 operators. Ø Automatic water intake range: Horizontal 12m, vertical 15–30m, intake time within 3 minutes. Ø Manual water intake range: Horizontal 13–60m, intake time within 10 minutes. Ø Onboard fuel supports continuous operation for 6 hours; system can run continuously for 168 hours. Ø Maximum water supply distance condition: Single main hose line, outlet pressure 1.0 MPa, end pressure 0.3 MPa.
Water Flow Rate	Water flow rates available: 12,000, 15,000, and up to 18,000 liters per minute
Water Supply Pressure	1.0 MPa
Chassis	Built on high-quality chassis from world-leading brands
System Configuration	1 pumper fire truck Hose Laying Fire Truck for Long-Range Water Supply Systems (2 km hose capacity, expandable)
All configurations can be upgraded to extend the water supply range

（2）All-Weather, Fully Automatic Water Supply System (400–600 L/S)

Applicable Scope:Suitable for most water source areas, with distinct advantages in cold regions.

Performance:

	Pumper Fire Truck on 6x4 Chassis (Equipped with 1 Set of Floating Pump)
Specifications	Ø Each pumper fire truck and hose laying fire truck requires only 1–2 operators. Ø Automatic water intake range: Horizontal 16m, vertical 15–30m, intake time within 3 minutes. Ø Manual water intake range: Horizontal 17–60m, intake time within 10 minutes. Ø Onboard fuel supports continuous operation for 6 hours; system can run continuously for 168 hours. Ø Maximum water supply distance condition: Dual main hose lines, outlet pressure 1.0 MPa, end pressure 0.3 MPa.
Water Flow Rate	Water flow rates available: 24,000, 30,000, and up to 36,000 liters per minute
Water Supply Pressure	1.0 MPa
Chassis	Built on high-quality chassis from world-leading brands
System Configuration	1 pumper fire truck 2 Hose Laying Fire Trucks for Long-Range Water Supply Systems (4 km hose capacity, expandable)
All configurations can be upgraded to extend the water supply range
